MODEL 227
OPERATION MANUAL
Doc # 740063 Rev E
SECTION II - SPECIFICATION
2.3 MULTI-LEVEL FUNCTIONS - The following functions can be programmed to
change value during a given weld sequence.
FUNCTION POSSIBLE CHANGES
LEVEL TIME = 1 to 99 levels
PRIMARY CURRENT = 1 to 99 levels
BACKGROUND CURRENT = 1 to 99 levels
PRIMARY PULSE TIME = 1 to 99 levels
BACKGROUND PULSE TIME = 1 to 99 levels
PULSE MODE (ON/OFF/SYNC) = 1 to 99 levels
PRIMARY ROTATION RPM = 1 to 99 levels
BACKGROUND ROTATION RPM = 1 to 99 levels
ROTATION MODE (CONT/STEP/OFF) = 1 to 99 levels
PRIMARY WIRE FEED SPEED = 1 to 99 levels
BACKGROUND WIRE FEED SPEED = 1 to 99 levels
AVC MODE = 1 to 99 levels
PRIMARY AVC = 1 to 99 levels
BACKGROUND AVC = 1 to 99 levels
OSC AMPLITUDE = 1 to 99 levels
OSC DWELL and EXCURSION TIMES = 1 to 99 levels
2.4 NON-PROGRAMMABLE FUNCTIONS
WIRE FEED MODE SWITCH = ON/OFF
SYSTEM MODE KEY SWITCH = PROGRAM/OPERATE/LOCK
MANUAL PURGE = ON/OFF
2.5 AMBIENT TEMPERATURE RANGE - 32 F (0 C) to 110 F (45 C).
2.6 CABLE OPERATING DISTANCE LIMITS - Standard = 50 ft (15.2 m)
Maximum = 100 ft (30.5 m)
The standard distance consists of a 40 ft Pipe Weld Head Adapter cable and a 10 ft
Weld Head cable combined together. The maximum distance is achieved by
adding extension cables to the standard cables.
The above are considered normal limits and using a standard M227/207-CW or
M207-CW Cooling Unit Option. With special options, greater distances can be
achieved.Consult with an AMI technical representative for more information.
2.4
