MODEL 227
OPERATION MANUAL
Doc # 740063 Rev E
SECTION III - INSTALLATION
3.6 REMOTE PENDANT INSTALLATION
Always turn the power supply OFF before making any cable or connection
changes to
the M-227 power supply.
1. Insert the M-227-RP cable connector into the M-227 Panel connector
labeled REMOTE.
2. If a M-227-RP extension is used, it is installed between the M-227 and the
RP.
3. If required the M-227 can be operated without the RP Unit.
CAUTION
Installation is now complete but before proceeding with POWER ON it is
EXTREMELY important to have a basic understanding of SYSTEM
FUNCTIONS. Read section IV (system functions) before proceeding with
OPERATION (section V) or PROGRAMMING (section VI).
