Model 415
Operation Manual
NOTICE
This document and the information contained herein is the property of Arc Machines, Inc. It is proprietary
and submitted and received in confidence. It shall be used only for the purpose for which it is submitted and
shall not be copied in whole or in part without the prior express written permission of Arc Machines, Inc.
The information in this document has been carefully reviewed and is believed to be accurate. However, no
responsibility is assumed for inaccuracies.
Information and instructions in this document are subject to change and Arc Machines, Inc. reserves the right
to change specifications and data without notice.
WARNING
The nature of the GTAW process creates some POTENTIAL HAZARDS. In accordance with international
safety regulations the EXCLAMATION SYMBOL indicates that this equipment is considered HAZARDOUS
until an operator has been made aware of these POTENTIAL HAZARDS by READING THIS MANUAL. The
LIGHTNING FLASH SYMBOL indicates that there are potential electrical hazards. The use and display of
these symbols make it the OPERATOR’S RESPONSIBILITY TO INSURE THAT HE HAS READ AND/OR
BEEN MADE AWARE OF ALL OF THE SAFETY-RELATED ITEMS CONTAINED IN THIS MANUAL.
Publication date : First Edition - 1 July 1997
Copyright 1997 by Arc Machines, Inc.
All rights reserved
REV DCO # CHANGE DESCRIPTION DATE APR
A 3228 Revised pg. iv,2.1,2.2,3.2,3.5,Sect. 5 Add 3.11 1/27/99 GPE
B 3304 Revised pages iv, 2.1, 2.2, 3.5, 5.10 thru 5.20 4/20/99 GPE
C 3518 Revised Sec 5.6, corrected sec # error, added sec
5.18, 5.19, 5.20 updated Index page numbers
12/07/99 GPE
D 3548 Revised pages i, 2.1, 2.2 2/08/00 GPE
E 3632 Revised pages 3.2 and 3.3 5/18/00 GPE
F 3749 Revised page 2.5 Removed algaecide requirement 10/17/00 GPE
G 3779 Revised pages 5.1 to 5.11, Cal clarification 11/28/00 GPE
H 3829 Revised pages 5.1 to 5.8. change volt tolerance 03/15/01 LEC II
J 5229 Replace floppy drive with USB, update Section 3.3,
Remove Section 5.18, 5.19, 5.20
12/10/08 BF
K 5097 Correct Terminal Jumper Settings on page 3.5 12/18/08 BF
L 5450 Correct typo’s per BPMI-RS-P-02745, Update Input
Power Detail Section 2.0
9/29/09 BF
M 6245 Removed description of Neutral Overload (4.4.6) 2/7/12 SM
N 6412 Add CMOS battery replacement procedure section
5.18, reformat pagination
11/05/12 DC
Docume
nt No. 740084
Revision N
