AMI KW950-CR - Standard Synchro 360:1 Terminations

AMI Manual KW 950-CR Doc No: AMI TM950-CR
Manual KW950-CR Iss03 Rev03.doc
13
Standard Synchro 360:1 Terminations
DATA IN 2 (SK5)
A
B
DC INPUT (SK 1)
+
GND
0
24V DC
+V
0V
R1+
R2-
S1+
S1-
S2+
S2-
S3+
S3-
SYNCHRO 360:1
HEADING
R1
R2
S1
S2
S3
GYRO I/P (SK2)
NMEA PORT (SK 3)
A
B
GND
A
0
B
DATA OUT
KW950-E DISPLAY I/F
5V CMOS (SK 4)
DATA IN
+ 5V
D1
D2
0V
A
B
GPS NMEA
PRINTER
Pin 3 = A
Pin 7 = 0
