amiad EBS-10000 - Parts Schedule

EBS 10000 IL 910101-000109 / 09.17 Page 18 of 24
PARTS SCHEDULE
Refer to drawing on pages 19 – 21
No.
CAT. No.
DESCRIPTION
Qty.
1
710105-002603
10"EBS10K HOUS IL ASA150 EPXY555 ICEA300
1
2
760102-000068
HEX NUT M20 ZINC PLATED C/ST DIN934
16
3
760103-000070
FLAT WASHER M20 DIN125 ZINC PLATED C/ST
32
4
770102-000188
O-RING SEAL P2-471 (EBS-10000 LID)NBR
1
5
710105-001639
SCRN SUPP EBS-10K/MEGA CI AMRLK 400
1
6
770102-000126
O-RING SEAL (P2-237) NAT
1
7
710103-002924
LOWER BEARING EBS-40K/EBS-15K
1
8
770101-000059
O-RING SEAL71X5UP.BEARING DISC EBS NBR S
1
9
770104-000076
SHAPED SEAL HYD.AM-04NR EBS10000 SCR.NBR
2
10
700101-001033
WEAVEW.ST316 10000SQ.CM S300MIC F/EBS10K
1
11
700190-002639
SUCT SCAN ASSY WITH INTERNAL
1
12
710103-002547
SUCTION SCANNER SHAFT EBS
1
13
760105-000043
PIN 10X53 S/ST316
1
14
710103-002948
PLUG M12 FOR MEGA 19BAR
1
15
700190-002736
SCANNER ASSY OUTLET FILTER EBS-40000
1
16
710103-002827
PLUG POM FOR INTERN FILTER SCAN,EBS-15K
1
17
710103-002534
SUCTION SCANNER NOZZLE EBS
6
18
770101-000059
O-RING SEAL71X5UP.BEARING DISC EBS NBR S
1
19
710103-002611
UPPER BEARING EBS
1
20
770102-000077
O-RING SEAL P2-041EXTERN.UP.BEAR.G97NBR
1
21
710105-001502
LID EBS-10K ASA150/BS EPOXY555 ICEA-3002
1
22
760101-000358
HEX BOLT PARTIAL TH M20X100 Z.PLT C/ST
16
23
770102-000168
O-RIN.P2-433DRIV.UN.AD.EBS H-SAF NBR N/F
1
24
710105-001473
DR SHAFT HOUS EBS-10K EPOXY PKPK-3002
1
25
760101-000328
HEX BOLT PARTIAL THR M16X60 Z.PLT C/ST
8
26
760103-000069
FLAT WASHER M16 DIN125 ZINC PLATED C/ST
16
27
760102-000067
HEX NUT M16 ZINC PLATED C/ST DIN934
8
28
710105-001474
DR SHAFT HOUS COVER EBS EPOXY PKPK-3002
1
29
720202-000018
GEAR RMI70 FL 1/70 71 B5
1
30
760101-000314
HEX BOLT FULL THRD M10X40 Z.PLT C/ST
4
31
760103-000067
FLAT WASHER M10 DIN125 ZINC PLATED C/ST
8
32
760103-000086
SPRING WASHER M10 DIN127 ZINC PL. C/ST
4
33
760102-000064
HEX NUT M10 ZINC PLATED C/ST DIN934
4
34
710105-001582
DR SHAFT COVER EBS GEAR EPOXY PKPK-3002
1
35
760101-000524
SOCKET HEAD CAP SCREW M8X30 S/ST316
2
36
770103-000046
FLANGE GASKET 3" 124X92 NBR
1
37
730103-000517
3" BERMAD (400) HYD. VALVE ASA150 RED
1
38
760101-000329
HEX BOLT PARTIAL THR M16X65 Z.PLT C/ST
4
39
760103-000069
FLAT WASHER M16 DIN125 ZINC PLATED C/ST
8
40
760102-000067
HEX NUT M16 ZINC PLATED C/ST DIN934
4
41
730104-000220
BALL VALVE 3/4" M/F (BRASS/NI)
1
42
780101-000789
L-CONNECTOR 3/4" F/M GALVANIZED
1
43
010000-000042
3/4" FILTER BSPT AC BLACK SCREEN 200 MIC
1
44
770102-000082
O-RING SEAL P2-112 NBR"S"
1
45
710103-002569
RACCORD NIPPLE 1/4" FOR 3/4" FILTER
1
46
710103-002570
RACCORD NUT 3/4" FOR 3/4" FILTER
1
47
720501-000202
L-CONNECTOR 5/16"X1/4" 69F BRASS
3
48
710103-000591
PRESS CH POINT CONNECTOR 1/4"X1/4" BRASS
1
49
720103-000182
SOLENOID VALVE 24VAC NO ASCO RED HAT
1
50
720501-000206
CONNECTOR 5/16"X1/4" 68F BRASS
2
51
720502-000036
CONTROL TUBE 5/16" NYLON AIR BREAK
2.2M
