amiad EBS-10000 - Technical Specifications

EBS 10000 IL 910101-000109 / 09.17 Page 4 of 24
TECHNICAL SPECIFICATIONS
General
Maximum flow rate
800m
3
/h
3500USgpm
Consult manufacturer for optimum flow depending on
filtration degree & water quality.
Min. Operating pressure
2.5bar
35psi
Or lower if pressure is increased for flushing
Max. Operating pressure
10bar
150psi
16bar (240psi) upon request
Filter area
10,000cm
2
1550in
2
Inlet/Outlet diameter
200, 250, 300
and 350mm
8", 10", 12" and
14"
Flange standards as per request.
Filter housing diameter
500mm
20"
Max. Operating temperature
60
0
C
140
0
F
Weight (empty)
200mm = 506kg
250mm = 525kg
300mm = 550kg
350mm = 545kg
8" = 1,116lb.
10" = 1,158lb.
12" = 1,213lb.
14" = 1,202lb.
Flush data
Exhaust valve
80mm
3"
Flushing cycle time
30-40 seconds
30-40 seconds
Wasted water per cycle
500liter
132USgal
at 2bar (30psi)
Minimum flow for flushing
50m³/h
220USgpm
at 2bar (30psi)
Control and electricity
Electric motor
1/2 HP / 50 / 60 Hz, 18 / 22 Gear output R.P.M.
Rated operation voltage
3 phase, 220 / 380 / 440 V, 50 / 60 Hz
Single phase, 110 / 220 V, 50 / 60 Hz
Control voltage
24V AC
Current consumption
1.5 Amp. (with 3 phase 380V / 440V)
Construction materials
Filter housing and lid
Carbon Steel 37-2
Screen
Stainless Steel 316L
Cleaning mechanism
Stainless Steel 316, POM
Exhaust valve
Epoxy-Coated Cast Iron, Natural rubber
Seals
Synthetic Rubber, Teflon
Control system
Brass, Stainless Steel, PVC
Filtration degrees available
micron
500
300
200
130
100
80
50
25
10
mm
0.5
0.3
0.2
0.13
0.1
0.08
0.05
0.02
0.01
mesh
30
50
75
120
155
200
300
450
600
