Amibot Prime - Battery Removal; Product Specification

Battery Removal
1. Remove the screws on the battery cover with a screw driver.
2. Remove the battery cover.
3. Grasp the insulating tape at two sides of the battery and lift the battery.
4. Unplug the wire connector that links the battery and robot.
Note: Only use the original battery of the product, otherwise, it may cause product damage.
Product specifications
Classification
Item
Detail
Mechanical
Specifications
Diameter
340mm
Height
85mm
Weight
3.4Kg
Electrical
Specifications
Power Rating
24V, 600 mAh
Battery Specifications
Ni-MH 2000mAH, 14.4V
Cleaning
Specifications
Dust Bin Capacity
0.5L
Charging Type
Auto Charging/ Manual Charging
Cleaning Mode
One key to clean & Remote control selection
Charging Time
About 200~300 mins
Cleaning Time
90 minutes at maximum
Main Body Button Type
Touch (LED display)
Note: Particular specifications are subjected to change without prior notice.
16
