16
INSTALLATION
Connecting to electrical mains
Important!
Electrical connection must be made by a properly certied qualied installer. Do not
make any alterations in the appliance electrical system.
Tips for the installer
The hob is equipped with a terminal block allowing different connections appropriate for a
specic type of power supply.
Terminal block allows the following connections:
- single-phase 230 V ~
- two-phase 400 V 2N~
The hob can be adapted to a specic type of power supply by bridging the appropriate
terminals according to wiring diagram. Wiring diagram is placed on the hob's underside. The
terminal block can be accessed by removing the lid on hob's underside. Remember to match
the power cord to the type of connection and the hob's power rating.
Important!
Remember to connect the neutral lead to correct terminal block clamp, marked with
. The electrical system supplying the hob must be protected by a properly selected
tripping device or a circuit breaker allowing to disconnect the power supply in an
emergency.
Before connecting the appliance to power, please carefully read the information provided on
the rating plate and wiring diagram.
Connecting the hob other than shown on the wiring diagram may damage the hob.
CAUTION! The installer is obliged to provide the user with "appliance electrical connection
certicate" (enclosed with the warranty card). After installation, the installer should also provide
information on the connection made:
- single-phase, two-phase or three-phase,
- conductor cross-section,
- electrical protection (fuse type).
