DESCRIPTION OF THE APPLIANCE
Description of hob PB*2VQ203DFT
Control panel
1. Main sensor
2. Hotplate indicators
3. Minus sensor
4. Plus sensor
5. Key sensor with the lock function
6. Clock indicator
7. Minus sensor of the clock
8. Plus sensor of the clock
Back hotplate
Ø 180
Front hotplate
Ø 145
3
2
4
7
6
6
8
1
4
2
3
5
