WARRANTYANDAFTER-SALESERVICES
Warranty
Warranty service as stated on the warranty card
The manufacturer shall not be held liable for any damage caused by improper use of the product.
DOOR REVERSAL
6. Remove the two screws, which attach the lower hinge to the appliance door (Fig. 5). Take special care
and hold the appliance door with the other hand.
7. Holding the door, swing the lower door hinge away from the door using the other hand, then detach the
door from the appliance body (Fig. 6).
8. Remove the two screws , which attach the upper hinge to the body and the two screws holding the
lower hinge to the appliance body (Fig. 7).
9. Screw the upper and lower hinge on the opposite side of the appliance body using suitable screws (Fig.
8). Upper hinge should be mounted on the other side of the appliance as the lower hinge. The lower hinge
should be mounted on the other side of the appliance as the upper hinge.
With the hinges open, hold the door parallel to the appliance body and screw the hinges to the door using
suitable screws while taking proper care.
10. Make sure that the door is properly aligned with the appliance body (Fig. 9).
INSTALLATION OF THE APPLIANCE
Installation of the appliance should be performed by a qualied installer. The appliance should be placed in
furniture case (Fig. 10). Once the appliance is placed correctly, adjust the height of the appliance by turning
the 4 adjustable feet as appropriate. If necessary, adjacent Amica appliances should be braced with a bracket
xed by screws and tted in furniture (Fig. 11). There is a special strip at the top of the appliance. Attach it to
the underside of the cabinet with appropriate screws supplied with the assembly kit (Fig. 16). Decorative strip
must not block the vents located in the bottom casing unit, the strip must be cut to size (Fig. 17). The depth of
the bottom casing unit can be adjusted by moving it forwards or backwards. Once properly adjusted, tighten the
mounting screws (located in the openings on both sides of the casing unit) with a cross-head screwdriver. This
will permanently attach the casing unit (Fig. 18).
FITTINGFURNITUREBOARDTOAPPLIANCEDOOR
Place the mounting bracket on furniture board and position it accordingly (Fig. 12). The distance between the
furniture board and the underside of the worktop should be 5 mm (Fig. 13). Attach the mounting bracket using
suitable screws supplied in the installation kit. Pull out the mounting bracket cover and screw in the two special
screws (2) in the appliance doors(Fig. 14). Attach furniture board with the xed mounting bracket to the appliance
door. Secure the furniture board with suitable nuts (item 3, Figure 14). Make sure the furniture board assembly
is positioned correctly relative to the appliance (Fig. 15). Using the supplied screws, attach the furniture board
assembly to the bottom of the appliance door (Fig. 15). Replace the mounting bracket cover in its original location.
1. Unplug the appliance before reversing the door opening direction.
2. Remove food from the appliance.
3. Remove caps on the front of the refrigerator body (Fig. 1, Fig 2).
4. Remove the two screws, which attach the upper hinge to the appliance door (Fig. 3). Take special care
and hold the appliance door vertically.
5. Holding the door, swing the upper door hinge away from the door using the other hand (Fig. 4).
Beespeciallycarefulduringthisstep,asthehingemaycloseandcauseinjury.
