Specifications
Dimensions 605 x 270 x 156mm
(23
7
/
8
x 10
5
/
8
x 6
1
/
8
”)
Weight: 9.2kg (20lbs 4
1
/
2
oz)
Design: Ported, acoustic band-pass with built-in protection circuit
Compatability: Optimised for Amina AIW, Mobius and iQ series speakers
(can also be used with other 8Ohm speakers)
Power handling: 150W (continuous)
Nominal impedance: 4 Ohms
Frequency response: 36Hz – 140Hz (+/- 6dB), 18dB bandpass octave slope
Sensitivity: 86dB @ 1m/1W*
Maximum short-term SPL/1m: 108dB**
Port location: Front, side or end convertible + length adjustable
Port diameter I.D / O.D: 50.8mm (2”) / 55.8mm (2
3
/
16
”)
Connection: Spring-loaded post (bare wire)
* Corrected nearfield measurement
** Corrected nearfield port measurement. Assumes no in-room boundary loading which in
some cases may increase SPL by as much as 6dB.
Limited Warranty:
The ALF80 is designed to operate reliably for many years. Correctly installed and in
accordance with these instructions, Amina warranties the ALF80 against defective
materials and workmanship for a period of one year.
