4
Free Standing
The ALF80 can be positioned anywhere within a room and in any orientation. A location
near the corner of a room will give the most bass output however it is important to allow
the bass port to breathe. Do not place any solid objects closer than 50mm (2”) directly
in front of the port. Adhere the supplied rubber feet to the cabinet, this will protect the
product from dirt and scratches when positioned on the floor.
Fixing Brackets
Use the supplied brackets to secure the ALF80 to a solid structure. Use only the supplied,
13mm screws to fix the brackets to the cabinet. Never use longer screws as these may
damage the unit’s internal components. Ensure the brackets are not fixed over the port
plate, blanking plate or connection terminal.
Concealed Placement
The ALF80 can be placed within furniture, behind wall panelling or even within a ceiling
cavity. Whatever structure you install the ALF80 inside, it is important to create a suitable
opening for the port to protrude through allowing it to breathe into the listening room.
Use the brackets and screws provided to secure the ALF80 within the structure.
In-Ceiling
The illustration on the next page shows how the brackets supplied can be used to fix the
ALF80 to a ceiling joist.
Notice the port protrudes from the cabinet - this allows it to then protrude through a
suitable hole cut in the plasterboard ceiling layer.
The supplied Port Trim may be placed over the port opening to improve its appearance,
(this is detailed on the next page).
Positioning the ALF80
