A113X1 Development Kit User Guide
5.0 (2018-05-22) AMLOGIC, Inc. Proprietary
12
4. Debug Tool
4.1 UART Debug Tool
Install the CP210x USB to UART Bridge VCP Driver on the Windows PC/laptop:
Step 1. Navigate to https://www.silabs.com/products/development-tools/software/usb-to-uart-bridge-
vcp-drivers.
Step 2. Click ‘Download VCP’ (corresponding to your Windows OS version; no need for Serial Enumeration).
Step 3. Unzip the VCP zip file into a folder.
Step 4. Navigate to the folder with Windows Explorer and right-mouse click it to install it with administrator
privilege.
Step 5. Follow the steps in the installation program to completion.
Step 6. Connect the Micro USB to serial debug board & opposite end to Windows PC USB port.
Step 7. Bring up Windows Device Manager & expand Ports. Note the COM# for ‘Silicon Labs P210x USB to
UART Bridge’.
Step 8. Install Putty for Windows.
Step 9. Start Putty, click Serial, enter COM# (replace with number viewed in step 4), 115200 for the baud
rate, & click Open.
Step 10. Plug the 12V plug into the A113X main board power jack and the adapter into an electric outlet.
Step 11. Slide the tall black power-up switch immediately behind the power inlet on the A113x main board to
power up the board.
Step 12. Observe that the boot up output appears in the Putty terminal window.
4.2
Usage of ADB and Telnet
ADB tool
Connect the USB cable between PC and board, and execute the command on CMD as below:
