Second segment
Drive the Machine slowly forward by about 2,4 m (7,88 ft).
Use four clamps to x on each side. Before tightening even up
segment edges with the edge of the drum.
Suspend the second segment across the openings in the lugs in
the same way as the rst segment.
Position the second segment so that there is a gap between the
segment ends of about 26 mm (1,02 in).
Connect segments using material (560-10), (560-13), (560-16).
While checking the clamps so that they
wouldn’t interfere with the drum frame.
