176 ASC 110
21
BACLIGHT DIMMER
FUEL LEVEL
396331
*
SET EMPTY POINT
SET FULL POINT
SET LOW FUEL LEVEL
396332
2
1
*
396333
SET EMPTY POINT
SET FULL POINT
SET LOW FUEL LEVEL
396334
2
1
*
*
19. Disassembly of the floater
Move cursor 1 to FUEL LEVEL, conrm with Enter 2.
Move cursor 1 to SET EMPTY POINT 2, conrm with Enter.
Turn the fuel gauge by 180° (full tank). Leave it in this position
for the settings as follows.
Move cursor 1 to SET FULL POINT, conrm with Enter 2.
