52 ASC 110
5. Drum Dismounting
Technical data
Description
The vibrating drum with carriers is xed on both sides in the front frame by means of metal rubber parts of the prescribed strength.
The vibrating eect is generated by two pairs of cams on both sides of the drum. The cams are interconnected using a shaft. The cams
are driven by a hydraulic motor – the drum left side. The drum is driven by a hydraulic motor – right side.
Vibrating roller service uids l (gal US)
Drum – vibrator housing – engine oil – API CD EP; SAE 15 W/40 8,0 (2.1)
Reducer – engine oil – API GL-5
SAE 80 W/90 for an ambient temperature of -10 °C ÷ +30 °C (14 °F ÷ 86 °F)
SAE 80 W/140 for an ambient temperature of +20 °C ÷ +45 °C (68 °F ÷ 113 °F)
4,2 (1.11) - ASC 110 HD, HDPD
4,8 (1.27) - ASC 110 HT, HTPD
Lubricating grease – ISO 6743/9 CCEB 2, DIN 51 502 KP2K-30 as required
