AMP Research BedXTender HD Max 74840-00A - Parts List and Hardware Identification

rev 05.14.19
2/6
www.amp-research.com
AMP RESEARCH BEDXTENDER HD™
10
PARTS LIST AND HARDWARE IDENTIFICATION
Quick Mount
Bracket Set
1
x2
Phillips head
screw
(included in 74608-01A)
2
x6
x4
4
Bumper
Center Tube
3
PT-Screw
x12
x2
5
Strap Buckle Assembly
Rest lower edge on
lower tailgate bumper.
RAM Bed Extender - Drill Template
Driver Side
Mark all three hole locations
with center punch and then
drill hole size to 5/32” (4mm)
CAUTION: Make sure center punch indentations are deep enough to prevent the drill bit from wandering. Misdrilled holes may adversely aect installation of brackets.
BEND DOWN 90°
BEND UP 90°
TAPE
TAPE
TAPE
CAUTION: Make sure center punch indentations are deep enough to prevent the drill bit from wandering. Misdrilled holes may adversely aect installation of brackets.
BEND DOWN 90°
BEND UP 90°
RAM Bed Extender - Drill Template
Passenger Side
TAPE
TAPE
Rest lower edge on
lower tailgate bumper.
Mark all three hole locations
with center punch and then
drill hole size to 5/32” (4mm)
TAPE
Drill Templates
6
x2
Pivot Upright Assembly
7
x2
Bumper Upright Outer
8
x2
Bumper Upright Inner
9
x3
