AMP Research BEDXTENDER HD MAX 74841-00A - Parts List and Hardware Identification

rev 05.02.19
2/7
www.amp-research.com
AMP RESEARCH BEDXTENDER HD™
PARTS LIST AND HARDWARE IDENTIFICATION
Quick Mount
Bracket Set
1
x2
x4
3
Bumper
(Small Silver)
(Small Silver with LOGO)
(Small Black)
(Small Black with LOGO)
(Large/Deep Black)
(Large/Deep Black with LOGO)
(Large/Deep Silver)
(Large/Deep Silver with LOGO)
Center Tube
2
PT-Screw
x12
x2
4
Strap Buckle
Assembly
10
x2
Silver: (Small)
Black: (Small)
Silver: (Deep)
Black: (Deep)
Silver: (Large)
Black: (Large)
Pivot Upright Assembly
5
x2
(Small/Narrow)
(Large/Deep)
Bumper Upright Outer
6
x2
(Small/Narrow)
(Large/Deep)
Bumper Upright Inner
11
x3
7
x4
M8 Bolt
8
x4
M8 U-Nut
9
x4
Bracket Nut
Plate
