AMP RESEARCH BEDXTENDER HD™
MOUNTING BRACKET INSTALLATION - CHEVROLET SILVERADO / GMC SIERRA 2019
PLEASE READ ENTIRE INSTRUCTIONS BEFORE PROCEEDING WITH INSTALLATION
Remove the tail lights using T20 torx driver. Carefully pull back to remove tail lights.
Assemble U-Nuts on to bracket plates in the
orientation shown.
1
4x
M8 Bolt
Driver Passenger
4x
M8 U-Nut
4x
Bracket Nut Plate
