AMP RESEARCH BEDXTENDER HD™
BED X-TENDER ASSEMBLY
Adjust the width of the BEDXTENDER by placing
the pivots into the mounting brackets. To keep
overlap consant, adjust each tube so that the gap
between the edge and the tape is the same.
3
4
5 6
Slide 3 center tubes into the open ends of the bent
tubes as shown. Insert center tube with logo into the
center tube.
Connect the two halves. Make sure there is at least
3” overlap with the bent tubes on each side.
Measure 7” from each end of the three center
tubes and mark with tape. Tape is to be used as a
reference point
11
10
11
11
Note: Template
located on inside
of box.
11
10
