LED Indicators
Power: Indicates when the Dual Band Repeater is powered on. The LED will remain on.
5.0GHz Wireless Activity: Blinks rapidly when wireless data traffic is transmitted or
received over the 5.0GHz wireless network.
2.4GHz Wireless Activity: Blinks rapidly when wireless data traffic is transmitted or
received over the2.4GHz wireless network.
Gigabit Wired Ports 1-5: Indicates when a networking device is connected to a wired
port on the back of the Dual Band Repeater. The LED blinks rapidly when wired data
traffic is transmitted or received.
USB Connection: Indicates when a USB storage device is connected to the USB port for
local sharing.
WPS: Wi-Fi Protected Setup activity. When the WPS mode is activated the WPS LED
blinks as it awaits a connection.
