Page 44 OM020-9 Model 270 Operating Manual
Diagram 2: Model 270 used with the medically-approved mains
adapter and printer
Mains Outlet Medical Mains Adapter
Model 270
Audiometer
Mains Outlet
Printer
Printer via DATA socket
Power
Supply
