OM020-9 Model 270 Operating Manual Page 45
Diagram 3: Model 270 used with the medically-approved mains
adapter and PC
Mains Outlet Medical Mains Adapter
Model 270
Audiometer
Mains Outlet
PC
Power
Supply
PC
via USB
socket
