MVP Modero Viewpoint Wireless Touch Panels
3
MVP-7500/8400 Modero Viewpoint Wireless Touch Panels
MVP Specifications
Memory (factory default): 64 MB SDRAM
64 MB Compact Flash (upgradeable to 1 GB - factory programmed)
Weight: 1.85 lbs (0.84 kg)
with 1 battery: 2.25 lbs (1.02 kg)
with 2 batteries: 2.65 lbs (1.20 kg)
MVP-7500 LCD
Specifications:
Aspect ratio: 4 x 3
Brightness (luminance): 120 cd/m
2
Channel transparency: 8-bit Alpha blending
Contrast ratio: 20:1
Display colors: 4096 colors (12-bit color depth)
Dot/pixel pitch: 0.23 mm
Panel type: TFT Color Passive-Matrix
Screen resolution: 640 x 480 pixels (HV) @ 60 Hz frame frequency
Viewing angles (vertical): + 17° / - 17° (from center)
MVP-8400 LCD
Specifications:
Aspect ratio: 4 x 3
Brightness (luminance): 180 cd/m
2
Channel transparency: 8-bit Alpha blending
Contrast ratio: 350:1
Display colors: 256K colors (18-bit color depth)
Dot/pixel pitch: 0.21 mm
Panel type: TFT Color Active-Matrix
Screen resolution: 800 x 600 pixels (HV) @ 60 Hz frame frequency
Viewing angles (vertical): + 60° / - 40° (from center)
Active Screen Area: 6.71" x 5.03" (17.04cm x 12.78cm)
External Components:
Docking station interface
connector:
Metallic strip connector located on the bottom panel provides communication
and power between the panel and the optional docking stations.
LEDs: Two sets of NetLinx programmable LEDs (supporting On, Off, and Blink).
Default blink patterns:
- Stylus LED: Blink = Batteries charging, On = Batteries charged.
- Front panel LED: Blink = Panel booting, On = Panel operating properly.
Mini-USB connector: 5-pin mini-USB connector for programming, firmware update, and file transfer.
Power connector: 2.1mm barrel-style power jack, for use with the included PS4.4 power supply.
Stylus slot: Illuminated slot where the included stylus is stored, located on the left side of
the MVP.
External Buttons: Nine programmable pushbuttons (four located on the left of the LCD and five
located on the right in a joystick configuration).
Internal Components:
Wireless Interface card: Provides 802.11 (CF Type I) wireless connectivity between the panel and a
Wireless Access Point (such as the NXA-WAP200G).
IR Emitters: Transmit IR over 20 feet (6.10 m).
Internal buzzer: Emits a Piezo electric tone (MVP-7500 only).
Internal speakers: One speaker for stereo output (MVP-8400 only).
Internal microphone For use with the intercom feature (MVP-8400 only).
Battery compartment: Houses up to 2 MVP-BP Power Packs.
