Analog way QuickVu - Communication Specifications

19
4.8.1 Serial interface
Please see the formats available on the output:
Output Type  Signal
Analog Computer
HDTV
Computer
Analog HDTV
Analog Computer
DVI-I Output
HDTV
Computer
Digital HDTV
Digital Computer
A standard RS232 interface is available through a DB9 female connector:
- It permits controlling the device
- It permits updang the device
Data Rate: 1200 to 115200 Bauds, 8 data bits, 1 stop bit, no parity bit, no ow control by default.
DTR & RTS needed for rmware upgrade.
4.8 
4.8.1 Serial interface

4.8.2.2 IP address
4.8.2 LAN interface
 Availability
TCP Yes
UDP Yes
 Availability
Stac user dened address Yes
A standard LAN interface is available through a RJ-45 connector
- It permits controlling the device
- It permits transferring conguraon
- It permits connecvity with the RCS² applicaon
- It permits updang the device
Default IP address: 192.168.2.140
