Anchor Event Series User Manual

15
1” x 32” Stake
Baseplate (6) hole
Diagonal Beam Brace
Upright
Upright
Baseplate (2) hole - use with L-pin (5/8”) & R Clip
L-Pin (16mm)
R Clip
Rafter/Upright Pin w/Flat
L-Pin - 16mm Drop-in
Gable End Uprights
Gable End Purlins
Locking L-Pin - 16mm w/Stop
Locking L-Pin - 16mm w/Stop
Intermediate Purlins
Ridge/Eave Purlin
Ridge/Eave Purlin
Rafter
Ridge Weldment
Ridge Brace (only when req’d)
Knee Brace (only when req’d)
Gable Upright Connector Plate
Figure 2.1
Note: See pages 4 to 6 for actual
confi guration of your structure.
Shown for example here is a 25m.
