Anchor Event Series User Manual

16
Upright
Rafter/Upright Pin w/Flat. Place
inside end of Rafter and down
thru open hole and upright after
upright is slid into slide fi tting.
Ridge Weldment
Wood Blocking
(Typ.)
Rafter
Slide Fitting
Rafter
Figure 2.2a
Figure 2.2b
Locking L-Pin
16mm w/ Stop (typ.)
Locking L-Pin
16mm w/ Stop (typ.)
Ridge Brace (only
when required)
Knee Brace (only
when required)
Final position
Final position
