SPECIFICATIONS
Explorer PRO
Rated power output: 60 watts (AC mode) / 30 watts (DC mode)
Max SPL @ rated power: 110 db @ 1 meter
General
Frequency response: 80 Hz - 16 kHz
Speaker type: 6.5" woven fiber woofer, high-output horn tweeter
Inputs
Microphone inputs: Lo-Z (1 kΩ), balanced, XLR
(two universal jacks) 12 VDC condenser mic (phantom) power
Hi-Z (10 kΩ), unbalanced, 1⁄4"-phone
Auxiliary (line) input: Hi-Z (10 kΩ ), unbalanced, 1/8” stereo, 1⁄4"-phone
Sensitivity for rated output
Line: -8.4 dBV (380 mVrms)
Mic (unbalanced): -49 dBV (3.63 mVrms)
Mic (balanced): -49 dBV (3.63 mVrms)
Outputs
Line output (post fader): Lo-Z, buffered, dual RCA/1/4” unbalanced/balanced
Speaker output: 2Ω, unswitched, 1⁄4"-phone
AC Power requirements: 90 - 264 VAC, 50/60 Hz
Dimensions (HWD): 16.5 x 10.5 x 10", 42 x 27 x 25 cm
Weight: 23 pounds, 10.4 Kg.
Certification
This system conforms to part 74 and part 15 of the FCC rules, contact the
FCC office for filling forms.
Frequency Range: 682 MHz - 698 MHz
WH-6000EU and WB-6000EU transmitters meet the essential requirements
of the European R&TTE Directive 99/5/EC and are eligible to carry the CE
marking. CE 0336 !
European Frequency Range: 863.125 MHz - 864.875 MHz
Specifications subject to change without notice.
