Step 8: Installing baffle filters
•
To install baffle filters, refer to Figure # 9 for the following four steps:
Angle baffle filters toward back of the hood
Slide the handle toward the metal filter handle and push up
Release the handle until it fits into resting positions
Repeat to install all baffle filters.
Turn power ON in control panel. Check all lights and fan operations.
Make sure to leave this Installation Guide for the homeowner.
