GENERAL INFORMATION
Due to the best choice of materials and high precision in manufacturing, we recommend, for
normal use, only to dismantle, clean and lubricate the winch once every second year. Under
extensiveuse,suchasracing,charterorbluewatersailing,werecommendtolubricatethe
winch once every year.
We strongly recommend always to use ANDERSEN WINCH GREASE, when lubricating your
winch.ANDERSENWINCHGREASEisahighqualitysilicone/Teongreaseproduct.
Mostothertypesofgrease,including“marinegrease”arenotsuitableforlubricationof
winches. Non-suitable grease products can cause malfunction, which could result in fatal
injuries for the user and others.
Pawl arm springs should be replaced every second year. Spare arm springs and other parts
thatmayberequiredareincludedintheANDERSENServiceKit.Pleaserefertotheservice
instruction for the Service Kit suitable for the specific winch.
When the winch handle is not in use but the winch is under load, we recommend, from a
safety point of view, to remove the winch handle from the winch.
To ensure correct function of the self-tailing unit, only use recommended line sizes. When
using the winch with mooring lines DO NOT use the self-tailing function and be sure that the
mooring line is not in contact with the self-tailing arm.
To ensure the best possible functioning of the winch, we recommend that
the winch is placed in accordance with the line entry (shown below).
Be also aware that the self-tailing arm is positioned correctly. We recommend to have the
self-tailing arm positioned within the shaded area (shown above). On this model the self-
tailing arm can be placed in several dierent positions after having installed the winch.
To identify the Output Drive Gear, insert a winch handle into the winch
androtateinbothdirections,thedrivegearwillonlyrotateclockwise
in a fast and slow speed.
Ideal
rope
entry
Output
drive
gear
p6
40ST (V.5.0)
40ST FS (V.5.0.F)
