Andonstar ADSM302 - Connect & Outputs; Software Installation

Andonstar ADSM302 Digital Microscope
- 6 -
Connect & Outputs
The ADSM302 has 5 possible outputs: its own monitor, HDMI, AV/TV, USB and memory card.
①：AV output *
②：Memory card
③：USB output *
④：HDMI output *
⑤：Connect the device to the switch.
⑥：Connect the switch to the power supply.
⑦：Connect the two goose lights to the switch.
⑧：3-button switch (ON/OFF, goose light brightness up/down)
