User’s Manual for Node G
Network Elements
Page 30
M0121A2A.doc
Using a Node G x30 as an example, the following figure illustrates the positions of
the RF components inside the Node G.
figure 4-2 RF path of a Node G x30, exemplary
DL final amplifier
Power supply unit
Duplexer with LNA
Digital channel
module with
integrated controller
Duplexer
UL IN DL IN
