PARTS LIST RFF190 & RFF280 SECTION 8
25
Model RFF190 RFF280
Ref. Part Numbers Description Qty
A1 E163 E164 Hot Outlet Nipple/Anode 1
A2 E165 E166 Hydrojet Cold Inlet Diptube 1
A3 C247 C247 3/4NPT x 3/4 BSP Nipple 1
A4 C103 C103 Socket Coupler 1
A5 C381 C381 Drain Cock 1
A6 E533 E533 Flue Baffle 1
A7 E168 C660 Cover, Combustion Chamber 1
A8 E169 C329 Cover, Burner Access 1
A9 E501 E501 Thermostat Cover Access 1
B1 E502 E503 Burner Assembly 1
B2 E504 E504 Pilot Supply Pipe 1
B3 E174 E530 Burner Supply Pipe 1
B4 E353 E353 Burner Head 1
B5 E505 E505 Gas Control Valve
B6 E531 E532 Injector 1
B7 C382 C382 Gas Cock 1
B8 E506 E506 Spark Ignition Control 1
B9 E507 E507 Pilot Burner Jet N18 1
B10 E508 E508 Pilot Assembly 1
B11 E509 E509 Thermostat 1
B12 E561 E561 1/2” BSP M/F Elbow 1
C1 E510 E511 Flue Fan Assembly 1
C2 E512 E513 Air Pressure Switch 1
C3 E554 E554 Flue Fan ECO 1
Ref. ANDREWS Part Numbers Description Qty
B176 Flue Terminal Assembly 1
Comprises
E1 C791 Wall Outlet Terminal (includes flue sleeve) 1
E2 E361 Flue 500mm x 80mm ø 4
E3 C792 Elbow 90º 1
E4 C790 Adaptor 1
Optional Extras
C794 Elbow 45º (Not Shown)
E5 E045 Flue Terminal
C793 Flue 1000mm x 80mm ø
NOTE:
Extra elbows and flue lengths can be ordered as required. Flue terminal is only used on vertical flue installations.
