1 SETTING UP THE PARENT UNIT
Charge the Parent
Unit 8 hours
prior to first use
Regular charging time
is 4 hours
8H
1
3
2
2 SETTING UP THE SENSOR PAD
e Sensor Pad is designed to detect subtle baby movements on the surface of the
mattress.e alarm will only sound if NO movement is detected for 20 seconds.
1
2
1. Remove the battery cover
and insert the battery face
with + face up
2. Replace the battery cover,
align 2 dots and click to secure
Correct positioning
for slatted base
3
3. Remove the mattress from
the cot, place Sensor Pad
- Angelcare® logo side
up - on base in approximate
centre of mattress. It should
be centred on the hardboard if
your cot requires a hardboard
support (see ‘IMPORTANT’ note
below)
4. Replace the mattress
