check the nameplate of the module you are using.
• The current and voltage generated by photovoltaic modules under certain conditions may be higher than those under standard
test conditions. If the installation conditions do not meet NEC requirements, the rated voltage of the module can be determined
by multiplying the Isc and Voc by a factor of 1.25, strengthening the current carrying capacity of the wire and the rated value of
the overcurrent protection device, as well as the capability of controlling the output end of the connected photovoltaic module.
• Anker's module design conforms to the international IEC61215 and IEC61730 standards and is rated class A for its application
level. It has passed IEC61730-1 and IEC61730-2 and is Class II safety-rated, making them suitable for systems requiring more
than 50V or 240W.
• Conforms to the Electrical Code - Part One - Electrical Equipment Safety Standard CSA C22.1-12-2012.
• All modules with exposed conductive parts are required to be grounded or otherwise regarded as violating UL 1703 under the
National Electrical Code of the United States and the installation manual.
• For installation methods and guidance on fire safety, consult the local competent authorities.
• To evaluate the fire rating of the system, the roof and mounting brackets must be covered with fireproof material and ventilated
while still complying with local electrical safety regulations.
• Dierent roof structures and installation methods will aect the fire safety performance of the building. If not properly installed,
it may lead to a fire. Module frames must be spaced 115mm (4.5in) apart from roof surfaces to ensure fire protection. Electrical
safety regulations require the use of appropriate module accessories, such as fuses, circuit breakers, and earthed connectors.
• The installation manual for the solar PV module outlines safety precautions. Ensure that the roof structure is stable and secure
before installing the modules. All roof-mounted modules must be sealed to prevent water leakage and ensure compliance with
fire safety standards. Dust accumulated on the surface will damage the performance of the module. The installation angle
should be kept above 10° so that rain can wash away dust. Smaller inclinations will require more frequent cleaning.
• Do not operate the operating panel of any equipment near flammable gas.
Label
The label is located on the side of the microinverter. The label contains technical data, as well as the type and serial number of
the device. Safety instructions are listed and explained below:
Danger!
"Danger" describes an issue that, if ignored, can cause personal injury.
Attention!
"Attention" refers to circumstances that could cause property damage if disregarded.
Instructions for use!
"Instructions for use" states that installation and operating instructions are to be read and understood
before installation or repair.
Caution, hot surface!
"Caution, hot surface" warns that equipment surfaces may be hot and pose a burn risk.
Special disposal instructions!
"Separate disposal" indicates that this product may not be disposed of with normal garbage. Improper
disposal can damage the environment.
CE mark
The product complies with the essential requirements of relevant directives of EU.
TÜV NORD mark provides that conformity of products is verified by the internationally recognized
organization TÜV NORD and facilitates enterprises' access to international markets by increasing their
competitiveness and recognizability.
Double-insulated electrical appliances use reinforced protective insulation in addition to basic
insulation.
Installation
Read the instructions before installation. Damage caused by failure to follow instructions is not covered by warranty.
Section Notice
Permission
• When installing a solar panel on a balcony, make sure it can extend beyond the balcony railing.
• The solar PV system is grid-tied. Check with your local authorities to see if installation is allowed, and
the process may require approval before or after installation.
Installation
• Install or remove the PV system with caution. There must be no people or property beneath the work
area as it is a danger zone.
• During installation or removal, we recommend that at least three people work together. Ensure the solar
panel is firmly secured before tightening the hose clamps.
• The Mounting Auxiliary Rope must be connected to the balcony railing before the solar panel can be mounted.
• It is recommended to carry solar panels with at least two people. During installation, bumping or falling
will damage the glass surface of the solar panel.
• All installations should follow local electrical codes. Further protection of AC wiring from inverters
should be provided and may be required by local and national wiring regulations. This protection may
include Residual Current Devices, Earth Fault Monitors, and Circuit Breakers. This product may cause
AC current with a DC component. If a residual current-operated protective device (RCD) or a monitoring
device (RCM) is used for protection in case of direct or indirect contact, only an RCD or RCM of Type B is
allowed on the AC side of this product.
• There should be no changes made inside the microinverter other than the cable connectors.
Maintenance
• Never disconnect the solar panel from the microinverter without turning o the AC power. Before
removing the Schuko plug, the PV and AC connectors should not be disconnected under load.
• The brackets are only designed to withstand winds of level 8 (Gale, 39 - 46mph, which may break twigs
and small branches or make walking challenging). Additional protective measures may be necessary
during extremely windy weather, such as temporarily removing solar panels.
• If the brackets are rusted, deformed, or have any other conditions that aect their strength, it is
necessary to take protective measures immediately. These measures may include rust prevention,
reinforcement, or replacement.
• Do not damage the solar panel with sharp objects as it is made of glass.
• To receive maximum sunlight, solar panels should never be covered when in use.
• Never disconnect the DC wire connectors under load.
• Do not touch the heat dissipation surface of the microinverter. Please be aware of high temperatures
and keep them away from children.
• Do not attempt to repair the microinverter. It does not contain any user-serviceable parts. If
troubleshooting methods fail, please contact an authorized service agent.
Notice
CE RED Declaration of Conformity (For Microinverter)
This product complies with the radio interference requirements of the European Community. Hereby, Anker Innovations Limited
declares that the radio equipment is in compliance with Directive 2014/53/EU. The full text of the EU Declaration of Conformity is
available at the following website: https://www.anker.com
Maximum output power: 15 dBm (For EU)
Frequency band: 2.4G band (2.412GHz - 2.472GHz)
This symbol indicates that this product shall not be treated as household waste. Instead, it shall be handed over to
the applicable collection point for the recycling of electrical and electronic equipment.
