Specifications
Microinverter (A5140)
Input(DC)
Max Recommended PV Power(Wp) 450x 2
Max DC Open Circuit Voltage(Vdc) 60
Max DC Input Current (Adc) 14 x 2
MPPT Tracking Accuracy >99.5%
MPPT TrackingRange(Vdc) 22-55
Isc PV (absolute maximum) (Adc) 20 x 2
Maximum Inverter Backfeed Current to the Array (Adc) 0
Output(AC)
Max AC Output Power(Wac) 600
Maximum Inverter Backfeed Current to the Array (Adc) 230
Allowable Power Grid Voltage(Vac) configurable*
Allowable Power Grid Frequency(Hz) configurable*
THD <3% (at rated power)
Power Factor >0.99 (at rated power)
Rated Output Current (Aac) 2.61
Current (inrush)(Peak and Duration) 24A, 15us
Rated Frequency (Hz) 50
Maximum Output Fault Current (Aac) 4.4A peak
System Eciency
CEC Eciency 95.5%
Night Time Tire Loss(W) 0.11
Protection Functions
Over/Under Voltage Protection Yes
Over/Under Frequency Protection Yes
Anti-Islanding Protection Yes
Over Current Protection Yes
Reverse DC Polarity Protection Yes
Overload Protection Yes
Ground Fault Detection Integrated
Protection Degree NEMA-6/ IP-66 / IP-67
Ambient Temperature -40°C to +65°C (-40°F to +149°F)
Operating Temperature -40°C to +65°C (-40°F to +149°F)
Other Parameters
Display LED LIGHT
Communications
WiFi
Frequency: 2.4 Ghz
Standards: IEEE 802.11/b/g/n
Dimension (D-W-H mm) 277x132x50 mm (10.91”x5.20”x1.97”)
Weight(Kg) 2.9 (6.4 Ibs)
Environment Category Indoor and outdoor
Wet Location Suitable
Pollution Degree PD 3
Overvoltage Category II(PV), III (AC MAINS)
Other Parameters
Product Safety Compliance IEC/EN 62109-1 IEC/EN 62109-2
Grid Code Compliance* (Refer to the label for the
detailed grid code compliance)
OVE-Richtlinie R 25:2020
VDE-AR-N 4105:2018
DIN VDE V 0124-100 (VDE V 0124-100):2020
Solar Panel (A5500/A5501)
A5500 A5501
Electrical
Characteristics(STC)
Maximum Power - Pmax(W) 415 440
Open Circuit Voltage - Voc(V) 37.45 40.00
Short- Circuit Current - Isc(A) 14.02 13.80
Voltage at Pmax -Vmp(V) 31.61 34.56
Current at Pmax - Imp(A) 13.13 12.77
Module Eciency 21.3% 22.7%
Power Tolerance(W) (0, +4.99W) (0, +5W)
Maximum System Voltage(V) 1500Vdc (IEC) 1500Vdc (IEC)
Maximum Series Fuse Rating (A) 25A 25A
Mechanical
Specifications
External Dimensions 1722x1134x35mm 1706x1134x35mm
Weight 20.5Kg 22.0Kg
Solar Cells Mono crystalline 108(2x54) Mono crystalline 108(6x18)
Front Glass
AR Coated 3.2 mm tempered
glass
Class II
Frame Anodized aluminum alloy Anodized aluminum alloy
Junction Box IP68 IP68
Connector MC4 Compatible MC4 Compatible
Mechanical Load
Front Side Max. 5400Pa, Rear
Side Max. 2400Pa
Front Side Max. 5400Pa, Rear
Side Max. 2400Pa
Temperature
Characteristics
Pmax Temperature Coecient
-0.350%/℃ -0.290%/℃
Voc Temperature Coecient
-0.275%/℃ -0.242%/℃
Isc Temperature Coecient
+0.045%/℃ +0.054%/℃
Operating Temperature
-40~+85℃ -40~+85℃
Certification&Compliance
Solar Panel Tilt Mount (A5650)
Size (mm) Net Weight (kg)
U-shaped Rack 217*45*1.5 0.1
Vertical Support Scaolding 1100*110*1.5 1.34
Solar Panel Support Beam 1200*108*1.5 1.38
Lower Support Beam 618*102*1.5 0.73
Fastening Clamp 130*48*1.5 0.07
Limit Supports 92*40*2 0.05
