anko DL03L - Battery Installation (Remote Control)

REMOTE CONTROL AND GENERAL OPERATION
1. ON/OFF Button
2. Heating mode
3 & 4. Timer Button
5 & 6. Temperature Control Button
Increase the Temperature and Timer setting
Decrease the Temperature and Timer setting
BATTERY INSTALLATION (REMOTE CONTROL)
- First Time Use
Remove (pull) and discard the insulation film as shown on figure on the right.
- If the battery is flat, replace it as below:
1. Drive out the screw on the rear of the remote control.
2. Push and slide out the battery holder as figure 1 below.
3. Replace the battery with a new CR2025 button cell battery. The polarity markings are
shown on the rear of the Remote Control.
4. Close the battery holder.
Fig 1.
