Chapter 3 Measurement
3-42
3.8.1.2 Measurement Status Area
The measurement status is displayed. For details, refer to Table 3.8.1.2-1.
[1] [2] [3] [4]
Figure 3.8.1.2-1 Measurement Status Area
Table 3.8.1.2-1 List of displays the Measurement Status Area
No. Parameter Description
[1] Warm Up Indicates that the level and frequency are not stable
when the power is turned on.
[2] Level Over Displayed when the input signal level exceeds the input
range.
[3] Measure “Measure” display blinks while the measurement is being
executed.
[4] Storage Displays Storage Mode off/Average and Count for
Average.
