Antari M-7X - Technical Specifications

12
Breaker Reset
Disconnect AC power before reset breaker. Only replace fuse with same type
and rating.
Step 1: Disconnect AC power
Step 2: Flip breaker to ON position
Step 3: Turn on machine to test
Breaker
100V = 16A 250V
120V = 15A 250V
240V = 9A 250V
Technical Specifications
- Input voltage
- Rated power
- Light source
- Warm-up time
- Fluid consumption
- Fluid tank capacity
- Compatible fluid
- Ambient temp. range
- Output
- Control
- DMX channels
- Connection
- Optional accessories
- Dimension
- Weight
US model：AC 100-120V, 50 / 60Hz 13A
EU model：AC 220-240V, 50 / 60Hz 6.5A
1516W
22 x 3W LED (5 Red, 6 Green, 6 Blue, 5 Amber)
7 minutes (approx.)
200 ml/min
2.4L (0.63gal)
Antari FLC Super Light Fog Fluid
0°C - 40 °C (32 °F-104 °F)
10 meters height
DMX512, Timer, Manual, Wireless, Master/Slave
Wireless DMX (Optional)
9 channels
Neutrik TRUE 1 Connector (Power)
XLR 3-pin and 5-pin (DMX)
WTR-90 Wireless DMX
L344 W193 H381 mm (L13.54 W7.60 H15 inch)
14 kg (30.8 lbs)
