S
ECTION
4:
C
OOLING
S
YSTEM
4.1 T
RI
C
OOL
™
F
AN
Top TriCool™ Fan – The case comes with a 200mm top exhaust blue LED fan. The fan is installed so the
air will be blown out of the case. This fan comes with a three-speed switch that let you choose the speed
best suited to your need. The default fan speed setting is Low.
120mm TriCool™ Specifications
Size: 120 x 25mm TriCool™ fan
Rated Voltage: 12V
Operating Voltage: 10.2V - 13.8V
The Sonata III 500 comes with one pre-installed 120 x 25mm TriCool™ fan, located at the back of the
case. This fan is installed to blow warm air out of the case. The TriCool™ fan comes with a speed control
device attached to the fan housing. The default fan speed is Low.
Speed
(RPM)
Input
Current
Air Flow
Static
Pressure
Acoustic
Noise
Input
Power
High
2000
0.24A
(Max.)
2.2 m³ / min
(79 CFM)
2.5mm-H2O
(0.10 inch-H2O)
30 dBA 2.9 W
Medium
1600
0.20A
1.6 m³ / min
(56 CFM)
1.5mm-H2O
(0.06 inch-H2O)
28 dBA 2.4 W
Low
1200
0.13A
1.1 m³ / min
(39 CFM)
0.9mm-H2O
(0.04 inch-H2O)
25 dBA 1.6 W
Note: The minimum voltage to start a typical TriCool™ fan is 5V. We recommend that you set the fan
speed to High if you choose to connect the fan(s) to a fan control device or to the Fan-Only
connector found on some Antec power supplies. A fan control device regulates the fan speed by
varying the voltage, which may start as low as 4.5V to 5V. Connecting a TriCool™ fan set on Low
to a fan-control device may result in the fan not being able to start because the already lowered
voltage from the fan control device will be further reduced by the TriCool™ circuitry below 5V.
