Antelope sound.
For further information, you can also visit our support area online for the FAQ, Help Desk and to
register your product at: www.antelopeaudio.com (http://www.antelopeaudio.com).
Enjoy working with the new Orion32+!
All the best,
The Antelope Team
3. Features
●● Antelope Audio precise AD/DA conversion technology
●● 64 channels I/O Fiber Optic MADI
●● 32 channels at 192 kHz I/O via ThunderboltTM or custom-built USB chip
●● 32 channels AD/DA
●● 16 channels I/O via Fiber Optic ADAT
●● 2 channels I/O via S/PDIF
●● 1 x Monitor Out on TRS (2 channels)
●● Antelope’s renowned 64-bit Acoustically Focused Clocking Technology
●● Antelope’s proprietary Oven Controlled Oscillator for supreme clocking stability
●● 2 Word Clock Outputs, 1 Word Clock Input and 1 Atomic Clock Input
●● Five presets for fast and easy recall of favorite setups
●● 1U rack size device consuming only 20 Watts keeping the heat low
●● A user friendly desktop application available for both Windows ans OS X
●● Ergonomic software control panel
●● Extremely flexible routing and mixing capabilities
●● Massive parallel DSP and effects processing
4. Installation Guide
Windows:
1. Connect the USB cable to the USB port on your computer.
2. Download and install the Orion32+ software control panel and drivers from www (http://www).
antelopeaudio.com/en/support/downloads This will enable you to control your device
from your computer and select all necessary settings.
3. Open your control panel by double clicking and follow the device activation procedure.
4. Connect your choice of inputs and outputs to Orion32+.
5. The guest operating system will recognize the new output audio device (Orion32+).
6. If you want to use Orion32+ through USB for playback and recording, open your
preferred DAW and make sure the device is selected as an input and output.
Note: Make sure your device has the most recent firmware installed.
Mac OS:
Important Note
A Mac is compatible with Orion32+ only if it has the ThunderboltTM logo.
Mini DisplayPort
Thunderbolt Port
