Anttron TM220HD - 6 Technical Specifications

USER MANUAL
PAGE 12
ANTTRON ©2013
TM220HD
6 - Technical specifications
Video input Input HDMI
Resoluon modes 480p -576p -720p - 1080i
Compression H.264 – bitrate 5-15 Mb/s
Audio input Input HDMI
Sample Rate HDMI (32kHz / 44.1 kHz / 48 kHz)
Compression AAC-LC – bitrate 128-384 Kb/s
DVB Processing Table inseron PAT, PMT, SDT, NIT
Conguraon Channel/network name, SID, LCN, TSID, ONID, NID, versions, audio, video PIDs…
DVB-T output Output frequency / level 170-230 MHz + 470-862 MHz / > 80 dBµV
Constellaon - FEC QPSK/16QAM/64QAM - 1/2, 2/3, 3/4, 5/6, 7/8
Guard interval 1/4, 1/8, 1/16, 1/32
Mode - MER 2K/8K - 35 dB
DVB-C output Output frequency / level 50-862 MHz / > 80 dBµV
Constellaon - Symbolrate 16, 32, 64, 128, 256 QAM (EN 300 429) - 4,00 - 6,96 Msps
Power DC 2.1 mm connector +5V
Consumpon 10 Was
Dimensions LxWxH 170x130x35mm
Weight 0.6 kg
EAN code TM220HD 5420037692200
