Anttron TM220HD - 2 Description of the Different Elements

TM220HD
HD encoder
DVB-T / DVB-C output
USER MANUAL
PAGE 4
ANTTRON ©2013
2 - Description of the different elements
A1 Display
T1 CANCEL/RETURN button
T2 ENTER button
T3 u (move forward/down) button
T4 t (move backward/up) button
TM220HD
T1
T2
T3
A1
C1
C2
C3
OUTPUTINPUT
DC input
USB
C4
C6
HDMI
AUDIO INPUT
COMPONENT VIDEO INPUT
YPb Pr RL
C1 Power supply input (5V/4A)
C2 USB input (for programming
the TM250HD by PC)
C3 RF input
C4 RF output
C6 HDMI input
