Description 8 (20)
3.2.1 Connectors
1 2 3 4
1
2
Fig. 2
No Description
1 Power switch
2 Power connector (24 V)
1: 24 V
2: GND
3 RS232 connector
4 USB2 connector
Anybus
®
CompactCom Starter Kit Reference Guide HMSI-27-224 2.0
