Anybus CompactCom User Manual

Description 17 (20)
Header Signal
Name
Printed on
Board
Signal Name
Serial Mode Shift
Register
SPI Mode 8-bit Mode 16-bit Mode
JP17 D7 DIP2_7 DIP2_7 DIP2_7 D7 D7
D6 DIP2_6 DIP2_6 DIP2_6 D6 D6
D5 DIP2_5 DIP2_5 DIP2_5 D5 D5
D4 DIP2_4 DIP2_4 DIP2_4 D4 D4
D3 DIP2_3 DIP2_3 DIP2_3 D3 D3
D2 DIP2_2 DIP2_2 DIP2_2 D2 D2
D1 DIP2_1 DIP2_1 DIP2_1 D1 D1
D0 DIP2_0 DIP2_0 DIP2_0 D0 D0
JP20 OM0 OM0 OM0 OM0 OM0 OM0
OM1 OM1 OM1 OM1 OM1 OM1
OM2 OM2 OM2 OM2 OM2 OM2
nCS CS CS
nWE CT WE WEL
nIRQ PA IRQ IRQ IRQ
nOE OE OE
nRESET RESET RESET RESET RESET RESET
JP21 D15 LED4A LED4A LED4A LED4A D15
D14 LED4B LED4B LED4B LED4B D14
D13 LED3A LED3A LED3A LED3A D13
D12 LED3B LED3B LED3B LED3B D12
D11 LED2A LED2A LED2A LED2A D11
D10 LED2B LED2B LED2B LED2B D10
D9 LED1A LED1A LED1A LED1A D9
D8 LED1B LED1B LED1B LED1B D8
JP22 TxD . RX ASM RX ASM RX ASM RX ASM RX
RxD TX / OM3 ASM TX /
OM3
ASM TX /
OM3
ASM TX /
OM3
ASM TX /
OM3
IOC0 MI0 MI0 MI0/SYNC MI0/SYNC MI0/SYNC
IOC1 MI1 MI1 MI1 MI1 MI1
(NC)
(NC)
(NC)
(NC)
Signals TxD and RxD (JP22) are printed on the board as seen from the application. The signal
names for the different modes are given as seen from the brick.
Please refer to the Anybus CompactCom B40 Hardware Design Guide for more information.
Anybus
®
CompactCom Starter Kit Reference Guide HMSI-27-224 2.0
