Connecting the Monitor

Cable Connections In Back of Monitor:

1. HDMI

2. Analog (D-Sub 15-Pin VGA cable)

3. Earphone out

4. Power

Connect to PC

1. Connect the power cord to the back of the display rmly.

2. Turn off your computer and unplug its power cable.

3. Connect the display signal cable to the video connector on your computer.

4. Plug the power cord of your computer and your display into a nearby outlet.

5. Turn on your computer and display.

If your monitor displays an image, installation is complete. If it does not display an image, please refer Troubleshooting.

To protect equipment, always turn off the PC and LCD monitor before connecting.

Questions and Answers:

Need help?

Do you have a question about the AOC 22B3HM and is the answer not in the manual?

AOC 22B3HM Specifications

General

Panel type	VA
Pixel pitch	0.275 x 0.275 mm
Screen shape	Flat
Pixel density	93 ppi
Backlight type	W-LED
Display diagonal	21.5 \
Surface hardness	6H
Anti-glare screen	Yes
Adobe RGB coverage	104 %
Display technology	LCD
Native aspect ratio	16:9
Maximum refresh rate	75 Hz
NTSC coverage (typical)	87 %
Viewable size, vertical	268.11 mm
sRGB coverage (typical)	101 %
Contrast ratio (dynamic)	20000000:1
Contrast ratio (typical)	3000:1
Display number of colors	16.7 million colors
Viewable size, horizontal	476.64 mm
Display brightness (typical)	250 cd/m²
Brand-specific features	False
Certification	CE, FCC
Front bezel color	Black
Market positioning	Home
Exterior finish type	Matt
Mean time between failures (MTBF)	50000 h
Tilt angle range	-5 - 23 °
Height adjustment	-
Cable lock slot type	Kensington
Panel mounting interface	100 x 100 mm
HDMI version	1.4
Headphone connectivity	3.5 mm
Input current	1.5 A
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Socket connector type	C5
Power consumption (standby)	- W
Power consumption (typical)	20 W
Cables included	AC
HDMI cable length	1.5 m
Package type	Box
