AOC 22B3HM User Manual

20
Extra
Picture Boost OSD SetupExit
Luminance
Image Setup
Color Setup
Off Timer 00
Input Select Auto
Auto Config. No
Reset No
Image Ratio Wide
DDC/CI Yes
Resolution : 1920(H)X1080(V)
H. Frequency : 67KHz
V. Frequency : 60Hz
Extra
Game Setting
Input Select Auto/D-SUB/HDMI Select Input Signal Source.
Auto Cong Yes / No Auto adjust.the picture to default.
Off Timer 0-24 hrs Select DC off time.
Image Ratio wide or 4:3 Select wide or 4:3 format for display.
DDC/CI Yes / No Turn on or off DDC/CI Support.
Reset Yes / No Reset the menu to default.

AOC 22B3HM Specifications

General

Panel type	VA
Pixel pitch	0.275 x 0.275 mm
Screen shape	Flat
Pixel density	93 ppi
Backlight type	W-LED
Display diagonal	21.5 \
Surface hardness	6H
Anti-glare screen	Yes
Adobe RGB coverage	104 %
Display technology	LCD
Native aspect ratio	16:9
Maximum refresh rate	75 Hz
NTSC coverage (typical)	87 %
Viewable size, vertical	268.11 mm
sRGB coverage (typical)	101 %
Contrast ratio (dynamic)	20000000:1
Contrast ratio (typical)	3000:1
Display number of colors	16.7 million colors
Viewable size, horizontal	476.64 mm
Display brightness (typical)	250 cd/m²
Brand-specific features	False
Certification	CE, FCC
Front bezel color	Black
Market positioning	Home
Exterior finish type	Matt
Mean time between failures (MTBF)	50000 h
Tilt angle range	-5 - 23 °
Height adjustment	-
Cable lock slot type	Kensington
Panel mounting interface	100 x 100 mm
HDMI version	1.4
Headphone connectivity	3.5 mm
Input current	1.5 A
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Socket connector type	C5
Power consumption (standby)	- W
Power consumption (typical)	20 W
Cables included	AC
HDMI cable length	1.5 m
Package type	Box

Weight and Dimensions

Depth (with stand)	184.79 mm
Width (with stand)	492.44 mm
Height (with stand)	387.43 mm
Weight (with stand)	2620 g
Depth (without stand)	44.8 mm
Height (without stand)	292.3 mm
Weight (without stand)	2360 g
