Adjusting

Hotkeys

1 Source/Auto/Exit

2 Clear Vision/

3 Image Ratio/Volume/

4 Menu/Enter

5 Power

Menu/Enter

Press to display the OSD or conrm the selection.

Power

Press the Power button to turn on/off the monitor.

Image Ratio/Volume/

When there is no OSD, Press Volume button to active volume adjustment bar, Press“ ” or “ ”to adjust volume. When

there is no OSD, press“ ”hotkey continuously to change 4:3 or wide image ratio. (If the product screen size is 4:3 or input

signal resolution is wide format, the hot key is disable to adjust).

Auto / Exit / Source hot key

When there is no OSD, Press Auto/Source button continuously about 2 second to do auto congure. When the OSD is

closed, press Source button will be Source hot key function. Press Source button continuously to select the input source

showed in the message bar, press Menu/Enter button to change to the source selected.

Questions and Answers:

Need help?

Do you have a question about the AOC 22B3HM and is the answer not in the manual?

AOC 22B3HM Specifications

General

Panel type	VA
Pixel pitch	0.275 x 0.275 mm
Screen shape	Flat
Pixel density	93 ppi
Backlight type	W-LED
Display diagonal	21.5 \
Surface hardness	6H
Anti-glare screen	Yes
Adobe RGB coverage	104 %
Display technology	LCD
Native aspect ratio	16:9
Maximum refresh rate	75 Hz
NTSC coverage (typical)	87 %
Viewable size, vertical	268.11 mm
sRGB coverage (typical)	101 %
Contrast ratio (dynamic)	20000000:1
Contrast ratio (typical)	3000:1
Display number of colors	16.7 million colors
Viewable size, horizontal	476.64 mm
Display brightness (typical)	250 cd/m²
Brand-specific features	False
Certification	CE, FCC
Front bezel color	Black
Market positioning	Home
Exterior finish type	Matt
Mean time between failures (MTBF)	50000 h
Tilt angle range	-5 - 23 °
Height adjustment	-
Cable lock slot type	Kensington
Panel mounting interface	100 x 100 mm
HDMI version	1.4
Headphone connectivity	3.5 mm
Input current	1.5 A
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Socket connector type	C5
Power consumption (standby)	- W
Power consumption (typical)	20 W
Cables included	AC
HDMI cable length	1.5 m
Package type	Box
