12
Clear Vision
1. When there is no OSD, Press the “ <” button to activate Clear Vision.
2. Use the “ <” or “>” buttons to select between weak, medium, strong, or off settings. Default setting is always “off”.
3. Press and hold “ <” button for 5 seconds to activate the Clear Vision Demo, and a message of “Clear Vision Demo: on”
will be display on the screen for a duration of 5 seconds. Press Menu or Exit button, the message will disappear. Press
and hold “ <” button for 5 seconds again, Clear Vision Demo will be off.
Clear Vision function provides the best image viewing experience by converting low resolution and blurry images into
clear and vivid images.
Clear Vision
Off
Adjust the Clear Vision
Weak
Medium
Strong
Clear Vision Demo On or Off Disable or Enable Demo

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the AOC 22B3HM and is the answer not in the manual?

AOC 22B3HM Specifications

General IconGeneral
Panel typeVA
Pixel pitch0.275 x 0.275 mm
Screen shapeFlat
Pixel density93 ppi
Backlight typeW-LED
Display diagonal21.5 \
Surface hardness6H
Anti-glare screenYes
Adobe RGB coverage104 %
Display technologyLCD
Native aspect ratio16:9
Maximum refresh rate75 Hz
NTSC coverage (typical)87 %
Viewable size, vertical268.11 mm
sRGB coverage (typical)101 %
Contrast ratio (dynamic)20000000:1
Contrast ratio (typical)3000:1
Display number of colors16.7 million colors
Viewable size, horizontal476.64 mm
Display brightness (typical)250 cd/m²
Brand-specific featuresFalse
CertificationCE, FCC
Front bezel colorBlack
Market positioningHome
Exterior finish typeMatt
Mean time between failures (MTBF)50000 h
Tilt angle range-5 - 23 °
Height adjustment-
Cable lock slot typeKensington
Panel mounting interface100 x 100 mm
HDMI version1.4
Headphone connectivity3.5 mm
Input current1.5 A
AC input voltage100 - 240 V
AC input frequency50 - 60 Hz
Socket connector typeC5
Power consumption (standby)- W
Power consumption (typical)20 W
Cables includedAC
HDMI cable length1.5 m
Package typeBox
Weight and Dimensions IconWeight and Dimensions
Depth (with stand)184.79 mm
Width (with stand)492.44 mm
Height (with stand)387.43 mm
Weight (with stand)2620 g
Depth (without stand)44.8 mm
Height (without stand)292.3 mm
Weight (without stand)2360 g
