AOC 22B3HM User Manual

24
Specification
General Specification
Panel
Model Name
22B3HM
Driving System TFT Color LCD
Viewable Image Size 54.7
cm Diagonal
Pixel pitch
0.24825
(H
)mm x 0.24825
(V)m
m
Display Color
16.7M Colors
Others
Horizontal Scan Range
30k-
85
kHz
Horizontal Scan Size(Maximum)
476.64mm
Vertical Scan Range
48-75Hz
Vertical Scan Size(Maximum) 268.11 mm
Optimal Preset Resolution 1920x1080@60Hz
Max Resolution
1920x1080@60Hz(D-SUB)
1920x1080@75Hz(HDMI)
Plug & Play VESA DDC2B/CI
Power Source 100-240V~, 50/60Hz, 1.5A
Power Consumption
Typical(Default Brightness And
Contrast)
20
W
Max. (Brightness = 100, Contrast =100) ≤
23
W
Standby Mode ≤0.3W
Physical
Characteristics
Connector Type D-Sub/ HDMI/ Earphone Out
Signal Cable Type
Detachable
Environmental
Temperature
Operating 0°C~ 40°C
Non-Operating -25°C~ 55°C
Humidity
Operating 10% ~ 85% (Non-Condensing)
Non-Operating 5% ~ 93% (Non-Condensing)
Altitude
Operating 0~ 5000 m (0~ 16404ft )
Non-Operating 0~ 12192m (0~ 40000ft )

AOC 22B3HM Specifications

General

Panel type	VA
Pixel pitch	0.275 x 0.275 mm
Screen shape	Flat
Pixel density	93 ppi
Backlight type	W-LED
Display diagonal	21.5 \
Surface hardness	6H
Anti-glare screen	Yes
Adobe RGB coverage	104 %
Display technology	LCD
Native aspect ratio	16:9
Maximum refresh rate	75 Hz
NTSC coverage (typical)	87 %
Viewable size, vertical	268.11 mm
sRGB coverage (typical)	101 %
Contrast ratio (dynamic)	20000000:1
Contrast ratio (typical)	3000:1
Display number of colors	16.7 million colors
Viewable size, horizontal	476.64 mm
Display brightness (typical)	250 cd/m²
Brand-specific features	False
Certification	CE, FCC
Front bezel color	Black
Market positioning	Home
Exterior finish type	Matt
Mean time between failures (MTBF)	50000 h
Tilt angle range	-5 - 23 °
Height adjustment	-
Cable lock slot type	Kensington
Panel mounting interface	100 x 100 mm
HDMI version	1.4
Headphone connectivity	3.5 mm
Input current	1.5 A
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Socket connector type	C5
Power consumption (standby)	- W
Power consumption (typical)	20 W
Cables included	AC
HDMI cable length	1.5 m
Package type	Box

Weight and Dimensions

Depth (with stand)	184.79 mm
Width (with stand)	492.44 mm
Height (with stand)	387.43 mm
Weight (with stand)	2620 g
Depth (without stand)	44.8 mm
Height (without stand)	292.3 mm
Weight (without stand)	2360 g
